4-Way ball valve
PRODUCT SPECIFICATIONS
| DESIGN |
|---|
| ASME B16.34 |
| JIS B 2071 |
| STRUCTURE |
|---|
| BOLTED SIDE ENTRY |
| TOP ENTRY |
| RATING |
|---|
| CLASS 150 / JIS 10K |
| CLASS 300 / JIS 20K |
| SIZE |
|---|
| 1/2″ ~ 16″ / 15 ~ 400 |
| 1/2″ ~ 12″ / 15 ~ 300 |
| APPLICATIONS |
|---|
| Chemical and Petrochemical plants |
| Oil and Gas Production |
| Water Treatment |
| Food, Beverage, and Pharmaceuticals |
| END CONNECTION |
|---|
| ASME B16.5 |
| ASME B16.25 |
| DIN EN 1092-1 |
| JIS B 2220 |
| RF / FF / BW |
| FACE TO FACE |
|---|
| MANUFACTURE'S STANDARD |
| TEST |
|---|
| API 598 |
| JIS B 2003 |
| BODY MATERIAL |
|---|
| Carbon Steel |
| Stainless Steel |
| Special Alloy Steel |
| Monel / Alloy 625 / B148-C95800 |
| SEAT MATERIAL |
|---|
| PTFE |
| RTFE (Glass, Graphite, Carbon) |
| RTFM |
| DEVLON / PEEK |
| SPECIAL |
| BORE |
|---|
| FULL BORE |
| T-Port |
| L-Port |
| X-Port |
| Divert |
| FEATURES |
|---|
| Diverting of a fluid |
| Mixing of a fluid |
| Distribution of a fluid |
| Special Cleaning Service |
| Lever / Gear / POV / MOV |
