Floating type ball valve

Floating type ball valve

PRODUCT SPECIFICATIONS

DESIGN
ASME B16.34
API6D, API608
BS5351
JIS B2071
KS B2308
BONNET
BOLTED SIDE ENTRY
TOP ENTRY
RATING
CLASS 150 / 10K(0.98Mpa)
CLASS 300 / 20K(1.96Mpa)
CLASS 600 / 40K(3.92Mpa)
30K(2.94Mpa)

SIZE
1/2″ ~ 14″ / 15A ~ 350A
1/2″ ~ 8″ / 15A ~ 200A
1/2″ ~ 4″ / 15A ~ 100A
15A ~ 150A
TEMPERATURE(℃)
-46℃ to +250℃
END CONNECTION
ASME B16.5
ASME B16.25
DIN EN 1092-1
JIS B2220
RF / FF / RTJ / BW
FACE TO FACE
ASME B16.10
API 6D
JIS B2002
KS B2308
LEAKAGE CLASS
MSS SP 61
API598
JIS B2003
MATERIAL
Carbon Steel
Stainless Steel
Special Alloy Steel
SEAT MATERIAL
PTFE / RTFE
PEEK / DEVLON
BORE
FULL BORE
REDUCER BORE
FEATURES
FIRE SAFETY & ANTI-STATIC
SPECIAL CLEANING SERVICE
LOCKING DEVICE
TOXIC SERVICE VALVE
MOV / POV / VALVE
